Intermediate Metallic Conduit (IMC)
Product Features
-
Overview
RMC’s Intermediate Metal Conduit (IMC) (UL1242) is slightly more flexible than Rigid conduit, which makes it easier to bend and maneuver during installation but despite the thinner wall material IMC maintains excellent protection, strength and ductility for raceway systems. Our IMC conduit is manufactured from high strength hot-dipped galvanized steel and produced by the electrical resistance welding process which ensures continuous weld seams that will not split or crack at the weld and are free from interior defects. -
Consistent Quality
Made from high-quality flat rolled steel utilizing high production tube mills and the electric resistance welding method. Uniform galvanized protection and smoothness on the interior and exterior coatings. The inside surface is obstruction free and smooth to reduce friction between conduit wall and wire. Manufactured for long life – durable and strong. Threads are galvanized after cutting. No flaking or chipping when subjected to extreme stress. Easy to bend, cut and thread on the job. -
Locations
RMC’s IMC conduit meets the requirements of National Electrical Code Article 342 for use in indoor and outdoor locations and in wet and dry locations, including Class 1 Division 1 Hazardous Locations. IMC conduit provides exceptional physical protection, reduces exposure to EMF and shields against electromagnetic interference. -
Lower Life-Cycle Costs
Hot dipped galvanized coating provides enhanced corrosion protection. Physical and mechanical properties ensure that the pipe has an extended life cycle. Resists cracking, flaking, peeling, impact, and damage from severe bending. Impact-resistant and non-combustible. 100% Recyclable. -
Listings
Underwriters Laboratories Standard for rigid conduit (UL-1242) file # E531579. American National Standards Institute (ANSI® C80.6). National Electric Code® Article 342. Additional information can be found in the Underwriters Laboratories Inc., General information for Electrical Equipment Directory. The UL product category for IMC is DYBY.
Certifications
Underwriters Laboratories Standard for rigid conduit (UL-1242) file # E531579
American National Standards Institute (ANSI® C80.6)
National Electric Code® Article 342
Additional information can be found in the Underwriters Laboratories Inc., General information for Electrical Equipment Directory. The UL product category for IMC is DYBY.
| Part Number | Trade Size | Nominal WT. Per 100FT (30.5M) | Nominal Outside Diameter | Nominal Wall Thickness | Color Tape | Quantity In Bundle | Quantity Per Lift | Weight/Lift (lbs.) |
|---|---|---|---|---|---|---|---|---|
| IMCCT05 | 1/2 | 62 lbs / 28.12 kg | 0.815 in. / 20.70 mm | 0.078 in. / 1.197 mm | Yellow | 150 | 3500 | 2170 |
| IMCCT07 | 3/4 | 84 lbs / 38.10 kg | 1.029 in. / 26.14 mm | 0.083 in. / 2.10 mm | Green | 50 | 2500 | 2100 |
| IMCCT10 | 1 | 119 lbs / 53.98 kg | 1.290 in. / 32.77 mm | 0.093 in. / 2.35 mm | Orange | 50 | 1700 | 2023 |
| IMCCT12 | 1-1/4 | 158 lbs / 71.67 kg | 1.638 in. / 41.59 mm | 0.095 in. / 2.41 mm | Green | – | 1350 | 2133 |
| IMCCT15 | 1-1/2 | 194 lbs / 88.00 kg | 1.883 in. / 47.82 mm | 0.100 in. / 2.54 mm | Yellow | – | 1100 | 2134 |
| IMCCT20 | 2 | 256 lbs / 116.12 kg | 2.360 in. / 59.93 mm | 0.105 in. / 2.67 mm | Orange | – | 800 | 2048 |
| IMCCT25 | 2-1/2 | 441 lbs / 200.04 kg | 2.857 in. / 72.57 mm | 0.150 in. / 3.81 mm | Yellow | – | 370 | 1632 |
| IMCCT30 | 3 | 543 lbs / 246.30 kg | 3.476 in. / 88.29 mm | 0.150 in. / 3.81 mm | Orange | – | 300 | 1629 |
| IMCCT35 | 3-1/2 | 629 lbs / 285.31 kg | 3.971 in. / 100.86 mm | 0.150 in. / 3.81 mm | Yellow | – | 240 | 1510 |
| IMCCT40 | 4 | 700 lbs / 317.52 kg | 4.466 in. / 113.44 mm | 0.150 in. / 3.81 mm | Orange | – | 240 | 1680 |
